Docking station - for laptop - USB-C / USB-A - 3 x HDMI, DP - GigE
| Main Specifications | |
|---|---|
| Product Description | ALOGIC DV4 - docking station - USB-C / USB-A - 3 x HDMI, DP - GigE |
| Product Type | Docking station - for laptop |
| Docking Interface | USB-C / USB-A |
| Video Interfaces | 3 x HDMI, DP |
| Dimensions (WxDxH) | 6.8 in x 3.2 in x 1.1 in |
| Weight | 15.34 oz |
| Color | Black, space gray |
| Networking | Gigabit Ethernet |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station - for laptop |
| Width | 6.8 in |
| Depth | 3.2 in |
| Height | 1.1 in |
| Weight | 15.34 oz |
| Enclosure Color | Black, space gray |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD |
| Interfaces | 3 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x USB-C 3.2 Gen 1 - 24 pin USB-C ¦ 2 x USB-A 3.2 Gen1 - 9 pin USB Type A ¦ 2 x USB-A 2.0 - 4 pin USB Type A ¦ 1 x USB-C with Power Delivery (100 W) - 24 pin USB-C ¦ 1 x display / video - DisplayPort - 20 pin DisplayPort ¦ 1 x headphone/microphone combo jack - 3.5mm audio jack |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x USB-C to USB-A adapter ¦ 1 x USB-C cable - 2.6 ft |
| Features | 4K Ultra HD, 100W power delivery, pass-through charging |
| Compliant Standards | DisplayPort 1.2, DisplayPort 1.4 |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Video | |
| Max Resolution Details | 3840 x 2160 - 60 Hz (Single Display (DisplayPort / HDMI)) ¦ 3840 x 2160 - 60 Hz (Dual Display (DisplayPort + HDMI)) ¦ 3840 x 2160 - 30 Hz (Single Display (DisplayPort 1.2 / HDMI)) ¦ 3840 x 2160 - 30 Hz (Dual Display (DisplayPort + HDMI)) ¦ 1920 x 1080 - 60 Hz |
| System Requirements | |
| OS Required | Apple MacOS, Microsoft Windows, Google Chrome OS |
