Docking station - for tablet, notebook, desktop - Thunderbolt 4 - 2 x HDMI, 2 x DP - GigE, 2.5 GigE - 150 Watt
| Main Specifications | |
|---|---|
| Product Description | V7 DOCKTB4PT - docking station - Thunderbolt 4 - 2 x HDMI, 2 x DP - GigE, 2.5 GigE |
| Product Type | Docking station - for tablet, notebook, desktop |
| Docking Interface | Thunderbolt 4 |
| Video Interfaces | 2 x HDMI, 2 x DP |
| Dimensions (WxDxH) | 3.3 in x 8.9 in x 0.9 in |
| Weight | 17.6 oz |
| Color | Black, silver |
| Networking | Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Power | Power adapter 150 Watt Power Provided (DC 20 V) |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station - for tablet, notebook, desktop |
| Width | 3.3 in |
| Depth | 8.9 in |
| Height | 0.9 in |
| Weight | 17.6 oz |
| Enclosure Color | Black, silver |
| Expansion / Connectivity | |
| Interfaces | 2 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x network - RJ-45 ¦ 2 x audio / video - HDMI - 19 pin HDMI ¦ 1 x microphone / audio - mini-phone 3.5 mm ¦ 2 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 2 with Power Delivery (96 W) - 24 pin USB-C ¦ 2 x Thunderbolt 4 - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Input Device | SD card reader, microSD card reader |
| Cables Included | 1 x Thunderbolt 4 cable - detachable - 2.6 ft |
| Features | LED indicator, 2 security lock slots (cable lock sold separately), DisplayPort Alt Mode, ABS housing, high resolution support |
| Security Slot Type | Kensington nano security slot / Kensington security slot |
| Compliant Standards | FCC, RoHS |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az, IEEE 802.3bz |
| Power | |
| Power Device | Power adapter |
| Power Provided | 150 Watt |
| Voltage Provided | DC 20 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Video | |
| Max Resolution Details | 8K - 30 Hz (Single Display (DisplayPort / HDMI)) ¦ 4K - 30 Hz (Triple Display) ¦ 4K - 60 Hz (Dual Display) |
| System Requirements | |
| OS Required | Apple MacOS, Linux, Ubuntu, Apple iOS, Android 5.0 or later, Google Chrome OS 51 or later, Microsoft Windows 10 / 11 |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 6.3 in |
| Shipping Depth | 10.6 in |
| Shipping Height | 2.4 in |
| Shipping Weight | 2.31 lbs |
