Docking station - Thunderbolt 4 - HDMI, DP, 3 x Thunderbolt 4 - GigE - 150 Watt
| Main Specifications | |
|---|---|
| Product Description | SIIG Quad Display Thunderbolt 4 Docking Station & PD, Quad 4K 60Hz or 1x 8K, 3xTB4, 1x DP, 1xHDMI, 4xUSB-A,PD 60W,SD/TF - docking station - Thunderbolt 4 - HDMI, DP, 3 x Thunderbolt 4 - GigE |
| Product Type | Docking station |
| Docking Interface | Thunderbolt 4 |
| Video Interfaces | HDMI, DP, 3 x Thunderbolt 4 |
| Dimensions (WxDxH) | 7.8 in x 3.3 in x 1.1 in |
| Weight | 15.34 oz |
| Color | Black, space gray |
| Networking | Gigabit Ethernet |
| Power | Power adapter AC 100-240 V 150 Watt Power Provided |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station |
| Width | 7.8 in |
| Depth | 3.3 in |
| Height | 1.1 in |
| Weight | 15.34 oz |
| Enclosure Color | Black, space gray |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD |
| Interfaces | 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Display / video - DisplayPort - 20 pin DisplayPort ¦ Audio / video - HDMI - 19 pin HDMI Type A ¦ 2 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 1 x headphones - mini-phone 3.5 mm ¦ 1 x microphone - mini-phone 3.5 mm ¦ 3 x Thunderbolt 4 - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x USB-C cable - external |
| Features | Wake on LAN, DisplayPort Alt Mode, plastic housing, 100W power delivery (pass-through), aluminum housing |
| Compliant Standards | FCC, REACH, DisplayPort 1.4, RoHS 2.0 |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 100-240 V |
| Power Provided | 150 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Video | |
| Max Resolution Details | 8K - 30 Hz (Single Display) ¦ 4K - 60 Hz (Quad Display) ¦ 4K - 144 Hz (Single Display) |
| System Requirements | |
| OS Required | Apple macOS 10.12 or later, Windows 11 |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 6 in |
| Shipping Depth | 9.4 in |
| Shipping Height | 3.5 in |
| Shipping Weight | 3.02 lbs |
