Mini-dock - USB-C 3.2 Gen 1 / Thunderbolt 3 - HDMI
| Main Specifications | |
|---|---|
| Product Description | ATEN UH3239 - mini-dock - USB-C 3.2 Gen 1 / Thunderbolt 3 - HDMI |
| Product Type | Mini-dock |
| Docking Interface | USB-C 3.2 Gen 1 / Thunderbolt 3 |
| Video Interfaces | HDMI |
| Dimensions (WxDxH) | 1.4 in x 5.2 in x 0.4 in |
| Weight | 2.82 oz |
| Power | Power Provided |
| General | |
| Product Type | Mini-dock |
| Width | 1.4 in |
| Depth | 5.2 in |
| Height | 0.4 in |
| Weight | 2.82 oz |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SDXC Memory Card ¦ 1 (total) / 1 (free) x microSD |
| Interfaces | 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x USB-C 3.1 Gen 1 with Power Delivery (60W) - 24 pin USB-C ¦ 2 x USB 3.2 Gen 1 - 9 pin USB Type A |
| Miscellaneous | |
| Cables Included | 1 x USB-C cable - integrated - 1.8 ft |
| Features | 4K Ultra HD, 60W power delivery (pass-through) |
| Compliant Standards | Plug and Play, USB Power Delivery 2.0 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| System Requirements | |
| OS Required | Windows 10 or later, Apple iPadOS 13.1 or later, Apple MacOS X 10.12 or later |
