USB adapter - PCIe 2.0 - USB 3.0 x 7 - black
| Main Specifications | |
|---|---|
| Product Description | SIIG USB 3.0 7-Port PCIe Host Card - USB adapter - PCIe 2.0 - USB 3.0 x 7 |
| Device Type | USB adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 2.0 |
| PCI Specification Revision | PCIe 2.0 |
| Ports | USB 3.0 x 7 |
| Dimensions (WxDxH) | 0.8 in x 3.3 in x 4.7 in |
| Weight | 2.4 oz |
| Data Link Protocol | USB 3.0 |
| Data Transfer Rate | 5 Gbps |
| Processor | 1 x VIA VL805 / VL812 |
| Compliant Standards | USB 3.0, xHCI 1.0 |
| Color | Black |
| System Requirements | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016 |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | USB adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 2.0 |
| PCI Specification Revision | PCIe 2.0 |
| Expansion / Connectivity | |
| Interfaces | 7 x USB 3.0 - 9 pin USB Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS, UASP (USB Attached SCSI Protocol) |
| Color | Black |
| Networking | |
| Ports | USB 3.0 x 7 |
| Connectivity Technology | Wired |
| Data Link Protocol | USB 3.0 |
| Data Transfer Rate | 5 Gbps |
| Features | Over-current protection, USB Attached SCSI Protocol (UASP) |
| Compliant Standards | USB 3.0, xHCI 1.0 |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Processor / Memory | |
| Processor | 1 x VIA VL805 / VL812 |
| Dimensions & Weight | |
| Width | 0.8 in |
| Depth | 3.3 in |
| Height | 4.7 in |
| Weight | 2.4 oz |
