Docking station - USB-C 3.2 Gen 1 / Thunderbolt 3 - HDMI
| Main Specifications | |
|---|---|
| Product Description | ATEN UH3238 Travel Dock - docking station - USB-C 3.2 Gen 1 / Thunderbolt 3 - HDMI |
| Product Type | Docking station |
| Docking Interface | USB-C 3.2 Gen 1 / Thunderbolt 3 |
| Video Interfaces | HDMI |
| Dimensions (WxDxH) | 1.3 in x 3.5 in x 0.3 in |
| Weight | 1.76 oz |
| Power | Power Provided |
| General | |
| Product Type | Docking station |
| Width | 1.3 in |
| Depth | 3.5 in |
| Height | 0.3 in |
| Weight | 1.76 oz |
| Expansion / Connectivity | |
| Interfaces | 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 2 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 1 with Power Delivery (92 W) - 24 pin USB-C ¦ 1 x headphone/microphone combo jack - mini-phone 3.5 mm 4-pole |
| Miscellaneous | |
| Features | 4K Ultra HD, DisplayPort Alt Mode |
| Compliant Standards | Plug and Play, DisplayPort 1.4, HDCP 2.2, USB Power Delivery 3.0 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| System Requirements | |
| OS Required | Apple macOS Sierra 10.12 or later, Windows 10 or later, Android 8.0 (Oreo) or later, Apple iPadOS 13.1 or later |
