Webcam - color - 13 MP - 3840 x 2160 - audio - wired - USB 3.0
| Main Specifications | |
|---|---|
| Product Description | Jabra PanaCast 20 - webcam |
| Device Type | Webcam |
| Audio | Yes: built-in three microphones |
| Dimensions (WxDxH) | 1.7 in x 3.1 in x 1 in |
| Weight | 4.8 oz |
| Connectivity Technology | Wired |
| Camera | Color |
| Max Resolution | 3840 x 2160 |
| Frame Rate (max) | 30 frames per second |
| Video Modes | 720p, 1080p, 4K |
| Optical Sensor Type | 1/3.2" - 13 MP |
| Focal Length | 2.26 mm |
| Lens Iris | F/2.25 |
| Interfaces | USB 3.0 |
| Software Certification | Zoom Certified, Certified for Microsoft Teams, Optimized for UC |
| Cables Included | 1 - USB 3.0 Type C to Type A cable - 5 ft |
| Features | Picture-in-picture capability, LED indicator, High Dynamic Range (HDR), Intelligent-Zoom, USB video class (UVC 1.1), Manual Pan-Tilt-Zoom, integrated privacy cover, Intelligent Light Optimization, AI-powered |
| Manufacturer Warranty | 2-year warranty |
| Environmental Parameters (operating) | 41 °F - 95 °F |
| General | |
| Device Type | Webcam |
| Audio Support | Yes: built-in three microphones |
| Connectivity Technology | Wired |
| Width | 1.7 in |
| Depth | 3.1 in |
| Height | 1 in |
| Weight | 4.8 oz |
| Expansion / Connectivity | |
| Ports | USB 3.0 - Type C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Carrying case, USB cable |
| Cables Included | 1 x USB 3.0 Type C to Type A cable - 5 ft |
| Software Certification | Zoom Certified, Certified for Microsoft Teams, Optimized for UC |
| Compliant Standards | Plug and Play |
| Software / System Requirements | |
| Software Included | Software Development Kit (SDK) |
| OS Required | Apple macOS 10.15 or later, Apple macOS 11.x, Windows 8.1 / 10 / 11 |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Camera | |
| Type | Color |
| Max Digital Video Resolution | 3840 x 2160 |
| Video Modes | 720p, 1080p, 4K |
| Digital Zoom | 3 |
| Digital Video Capture Resolution | 1280 x 720, 1920 x 1080, 3840 x 2160 |
| Frame Rate (max) | 30 frames per second |
| Features | Picture-in-picture capability, LED indicator, High Dynamic Range (HDR), Intelligent-Zoom, USB video class (UVC 1.1), Manual Pan-Tilt-Zoom, integrated privacy cover, Intelligent Light Optimization, AI-powered |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 6.3 in |
| Shipping Depth | 5.1 in |
| Shipping Height | 2 in |
| Lens Construction | |
| Focal Length | 2.26 mm |
| Lens Iris | F/2.25 |
| Horizontal Field of View (degree) | 90 |
| Vertical Field of View (degree) | 75 |
| Diagonal Field of View (degree) | 117 |
| Image Sensor | |
| Type | 13 MP 1/3.2" |
| Interfaces | |
| Computer Interface | USB 3.0 |
