Network adapter - USB 2.0 - 802.11b/g/n - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | TRENDnet TEW-648UBM - network adapter - USB 2.0 - TAA Compliant |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB 2.0 |
| Dimensions (WxDxH) | 0.8 in x 0.3 in x 0.6 in |
| Weight | 0.04 oz |
| Data Link Protocol | 802.11b/g/n |
| Data Transfer Rate | 150 Mbps |
| Frequency Band | 2.4 GHz |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, Wi-Fi CERTIFIED, USB 2.0, IEEE 802.11n |
| System Requirements | Microsoft Windows 2000, Microsoft Windows XP, Microsoft Windows XP 64-bit Edition, Microsoft Windows 7, Microsoft Windows Vista, Microsoft Windows 7 64-bit Edition, Microsoft Windows Vista (64-bit versions) |
| Microsoft Certification | Compatible with Windows 7 |
| TAA Compliant | Yes |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Network adapter |
| Form Factor | External |
| Interface (Bus) Type | USB 2.0 |
| Expansion / Connectivity | |
| Connections | 1 x USB 2.0 - 4 pin USB Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Encryption Algorithm | 128-bit WEP, 64-bit WEP, WPA, WPA2, WPA-PSK, WPA2-PSK |
| Compatible with Windows 7 | "Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7. |
| Compliant Standards | ETSI, FCC |
| TAA Compliant | Yes |
| Networking | |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Spread Spectrum Method | OFDM, DSSS |
| Data Transfer Rate | 150 Mbps |
| Line Coding Format | OFDM |
| Frequency Band | 2.4 GHz |
| Max Range Indoors | 98 ft |
| Max Range Open Space | 328 ft |
| Status Indicators | Link/activity |
| Features | Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Wi-Fi Protected Setup (WPS) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, Wi-Fi CERTIFIED, USB 2.0, IEEE 802.11n |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows 2000, Microsoft Windows XP, Microsoft Windows XP 64-bit Edition, Microsoft Windows 7, Microsoft Windows Vista, Microsoft Windows 7 64-bit Edition, Microsoft Windows Vista (64-bit versions) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 0.8 in |
| Depth | 0.3 in |
| Height | 0.6 in |
| Weight | 0.04 oz |
| Antenna | |
| Antenna | Internal |
